Rated supply voltage(Un)

AC230V

Rated frequency

50/60Hz

Operation range

AC150~275V

Current actuation threshold

0.5~5A adjustable

Hysteresis

3% * actuation threshold value

Current measurement error

≤1%, True RMS measurement

Measurement frequency

50Hz

Max. input current

<10A

Trip delay

2s~40s

Reset delay

15s~300s

Trip delay error

±5%

U> trip value

260V

U> reset value

257V

U< trip value

160V

U< reset value

163V

Trip delay for voltage faults

0.5s

Power consumption

0.85W

Current load

8A/250V AC1

Output contact

1C/0

Contacts capacity

AC-15: 2A

Rated insulation voltage

250VAC

Max. fuse ratings

RT36-00 5A

Protection degree

IP20

Pollution degree

3

Electrical life

10⁵

Mechanical life

10⁶

Altitude

≤2000m

Ambient temperature

-25℃~+50℃

Permissable relative humidity

≤50% at 40℃（without condensation）
