Supply terminals

A1,A2

Rated supply voltage

AC220V

Rated frequency

50/60Hz

Voltage operation range

AC150-275V

U> threshold setting

225V~275V

U< threshold setting

165V~215V

Hysteresis

±3% of threshold setting value

Voltage measurement error

≤1%(over the whole range)

Trip delay

0.1~10s

Trip delay error

±5% +0.1s

Output contacts

11,12,14

Current rating

8V/AC1

Contacts capacity

AC-15:2A

Type of output

1C/0

Rated insulation voltage

250V

Max. fuse ratings

RT36-OO5A

Protection degree

IP20

Pollution degree

3

Electrical life

10⁵

Mechanical life

10⁶

Altitude

≤2000m

Operating temperature

-25℃~+50℃

Humidity

≤50% at 40℃（without condensation）

Storage temperature

-25℃~55℃

wire size

0.5mm²~1mm²
