Technical data
Supply terminals
A1-A2
Supply voltage
AC/DC24-240V
Rated frequency
50/60Hz
Power consumption
1.5W
Measuring terminals
T1,T2
Temperature range
-5~40℃
Hysteresis
-0.5~3℃
Output contacts
1C/0
Current rating
16A/250V AC1
Switching capacity
4000VA/AC1,300W/DC
Protection degree
IP20
Pollution degree
3
Electrical life
105
Mechanical life
106
Altitude
≤2000m
Ambient temperature
-20℃~+55℃
Humidity
≤50% @ 40℃（without condensation）
Storage temperature
-30℃~+70℃
Wire size
0.5mm2~2.5mm2
Torque
0.5Nm
Mounting
TH-35 Rail
Temperature sensor
Model
RT811
Measure element
NTC
Sensor d1mens1ons
ф6mmx5Dmm
Sensor material
Stainless steel
Cable size and length
2×0.5mm2/2.5m
Cable material
High temperature PVC
Function diagram
Operating instruction
Wiring diagrams
